working principle

The use of pressure swing adsorption principle of the gas dehydration drying, widely used in hydrogen, oxygen, natural gas and other special gas for deep dehydration drying.

Technical characteristics

1, the hydrogen, oxygen, natural gas and other special gases to dry;

2, equipment, renewable gas consumption less, low energy consumption;

3, finished gas dew point stability;

4, microcomputer control, LCD, LED real-time display device running status;

5, a variety of fault alarm and processing functions;

6, the heating control using non-contact solid state switch, temperature control overshoot, long life;

7, according to the requirements of explosion-proof design;

8, optional RS485 / RS232, linkage interface and dew point detection function;

9, reasonable structure design, easy to operate and maintain.

Technical indicators

Working pressure: 0.6 ~ 0.8Mpa (can be arch 0.8 ~ 3.0Mpa)

Finished product dew point: ≤ -40 ℃ or ≤ 52 ℃

Intake air temperature: ≤ 38 ℃

Regeneration gas consumption: ≤ 10%

Pressure loss: ≤0.02Mpa
